Spiral Mixer Machine

The China SYBO Spiral Mixer Machine is a high-efficiency, stable, and durable stationary dough mixing machine, particularly suitable for making bread, pizza, steamed buns, and other pasta products. It can be used in bakeries, restaurant chains, and food processing plants.

Send Inquiry

Product Description

SYBO's Spiral Mixer Machine comes in single-speed and dual-speed models. Different types of dough require different kneading strengths and speeds. Its fixed design makes it incredibly easy to use. Best of all, it features a timer setting ranging from 0 to 30 minutes. Operation is super simple: just set the time, and the machine will start working automatically and stop when the time is up.
Structural Features: The mixing bowl comes into direct contact with food. Therefore, our Spiral Mixer Machine is made of high-quality stainless steel. It fully complies with all food safety standards.
Our mixing hook and dividing rod have been specially reinforced. You may frequently handle large batches of dough, requiring significant effort. With this reinforced design, they can remain stable and durable, and are not easily deformed or damaged even if used every day or with great force.
The mixing hook and bowl of our Spiral Mixer Machine rotate simultaneously, resulting in well-kneaded dough with a smooth surface.
Our Spiral Mixer Machine uses a chain drive, which is more durable and operates with less noise.

Table parameters:

LF: Head Fixed

A=1 Speed

B=2 Speed

Model	Power	BowI Volume	Mixing Speed	Bowl Speed	Max.Dough	Max.Flour	Dimensions	N.W.
LF10A	0.7 kw	10L	157rpm	20rpm	6.4kg-60%water	4kg	775x380x760mm	70kg
LF10B	0.55/0.70kw	10L	115/229 rpm	17/34rpm	6.4kg-60%water	4kg	775x380x760mm	70kg
LF20A	1.5kw	20L	193 rpm	19rpm	13kg-60%water	8kg	840x420x900 mm	124kg
LF20B	1.1/1.5kw	20L	132/193 pm	13/19 rpm	13kg-60%water	8kg	840x420x900 mm	124kg
LF30A	1.5kw	30L	193rpm	19rpm	19kg-60%water	12kg	870x450×1020mm	129kg
LF30B	1.1/1.5kw	30L	132/193 rpm	13/19rpm	19kg-60%water	12kg	870x450×1020mm	129kg
LF40A	2.2kw	40L	193 rpm	19rpm	25kg-60%water	16kg	1000x510×1110mm	173kg
LF40B	1.5/2.2kw	40L	132/193 rpm	13/19rpm	25kg-60%water	16kg	1000x510×1110mm	173kg
LF50A	2.2kw	50L	193 rpm	19rpm	32kg-60%water	20kg	1003×530×110mm	177 kg
LF50B	2.2/2.5kw	50L	132/193rpm	13/19rpm	32kg-60%water	20kg	1003×530×110mm	177 kg
LF60A	2.2kw	60L	178rpm	18 rpm	40kg-60%water	25kg	1150x580×940mm	220 kg
LF60B	2.2/2.5kw	60L	118/178 rpm	12/18rpm	40kg-60%water	25kg	1150x580×940mm	220 kg

Model	Power	BowI Volume	Mixing Speed	Bowl Speed	Max.Dough	Max.Flour	Dimensions	N.W.
LR20A	1.5kw	20L	156 rpm	16rpm	13 kg-60%water	8kg	750x400×730mm	134kg
LR20B	1.1/1.5kw	20L	103/156rpm	11/16 rpm	13 kg-60%water	8kg	750x400×730mm	134kg
LR30A	1.5kw	30L	156 rpm	16rpm	19kg-60%water	12kg	790x430x830 mm	142kg
LR30B	1.5/2.2kw	30L	103/156rpm	11/16 rpm	19kg-60%water	12kg	790x430x830 mm	142kg
LR40A	2.2kw	40L	156 rpm	16 rpm	25kg-60%water	16kg	860x480x930mm	173kg
LR40B	1.5/2.2kw	40L	103/156rpm	11/16 rpm	25kg-60%water	16kg	860x480x930mm	173kg
